MILESIGHT EM300-DI LoRaWAN Pulse Counter

EM300-DI LoRaWAN Pulse Counter is used to remotely read metering data from water meters. It turns existing traditional water meters into smart meters via LoRaWAN® network which further enables easier management and increases the efficiency of water use.

Key Features:

• Superior Accuracy: Filter out Interference Signals Automatically; Configure the Device as Needed to Secure the Accuracy
• - Embedded with 2 Sensors: Temperature and humidity sensors for environmental monitoring
• - Data Storage, Retransmission and Retrievability: Stores over 2200 sets; retransmits data after reconnection to prevent loss
• - Long Battery Life: Single battery lasts 5 years; Dual batteries last 10 years
• - Easy Configuration: Via NFC technology from mobile phone or PC using Milesight ToolBox (Android/iOS)
• - IP67 Waterproof enclosure for harsh environment applications
• - Ultra-wide-distance transmission up to 10km line of sight
• - Compliant with standard LoRaWAN® gateways and network servers
• - LoRaWAN® Based | US915 Frequency Support
• - Ultra-Low Power Consumption

Specifications:

• Technology: LoRaWAN® | Frequency: US915 (also CN470/IN865/RU864/EU868/AU915/KR920/AS923)
• - GPIO Port: 1 × GPIO Interface, Dry Contact | Work Mode: Pulse Counter, Digital Input
• - Temperature Range: -30°C to +70°C | Accuracy: ±0.3°C (0–70°C)
• - Humidity Range: 0–100% RH | Accuracy: ±3% (10–90% RH)
• - Power Supply: 1 × 4000 mAh ER18505 Li-SOCl2 Battery (extendable to 2)
• - Ingress Protection: IP67 | Dimension: 105.6 × 85.2 × 27 mm
• - Installation: Screw Mounting | Operating Temp: -30°C to +70°C
• - SKU: EM300-DI-US915 | Brand: Milesight
